Standard Package DT465

Standard Package puts the additional information and reports needed by the business, including wider selection of accessories as well as basic information such as position, speed, and engine idling of passenger cars and commercial vehicles..
Battery Standard Package DT465B:
 It is the battery operated model of the standard package. The Battery Standard Package also offers a higher level of security by continuing to send data when the vehicle tracking unit is demounted.

  • USAGE AREAS

    It is a package supporting the additional optional accessories such as which driver uses the vehicle as well as all detailed information provided by the vehicle tracking system.

  • SPECIFICATIONS
    Network Specifications
    GSM/SMS/GPRS
    GSM 900/1800/1900 MHz
    900/1800/1900 MHz
    Detection of the Roaming Operator
    -
    Physical Dimensions
    Dimensions
    73 * 54 *22,7 mm
    Weight
    57 gr
    Connector
    10 pin Molex, otomotiv uygun
    Storage Temperature/Operating Temperature
    -40°C;+85°C / -30°C;+80°C
    Power
    Input Voltage
    9-32 VDC
    Power Saving Mode (Hybernation)
    Var
    Antenna
    GPS
    Dahili (harici anten ops.)
    GSM
    Dahili
    Hardware
    Telemetry
    3 Dijital + 1 Analog Giriş, 2 Dijital Çıkış
    Serial Port
    -
    Internal Battery
    DT465B Modeli
    Light Indicator
    Var
    Remote Firmware Upgrade
    Message Memory (unit)
    10000 (arttırabilir)
    Telemetry Specifications
    Digital Outputs
    2
    Digital Inputs
    3 (1 kontakt)
    Analogue Inputs
    1
    1-Wire
    1
    OBDII Port
    GPS Receiver Specifications
    Technology
    u-blox All-in-One GPS Receiver
    Receiver Sensibility
    -162dBm
    Cold Startup Time
    30 sn
    Hot Startup Time
    1.2 sn
    Warm Startup Time
    <30 sn
    Antenna
    Dahili (harici anten ops.)
    GPS Channel Number
    GPS+GLONASS 72 Kanal
    Protocol
    UDP Support
    TCP/IP Support
    SMS PDU
    Dinamic IP Destek
    Certificates
    CE
    E-mark
Standard Package DT465 ACCESSORIES
  • Emergency Call Button

    The Emergency Call Button can be used for sending an emergency call message to the centre, in cases of a malfunction, an accident or cases where it is necessary to take security precautions in the vehicle. The vehicle is taken under monitor by the centre. In Economics Package, the Emergency Call Button can not be used with Tank, Door Cover, Manhole Cover and Damper Sensors at the same time.

  • Tank / Door Cover Sensor

    The Door Sensor is an accessory that provides information regarding whether the vehicle’s door or the covers of the fuel tank etc. are open or closed. It can be used in cases of uncontrolled fuel supply, fuel stealing risk and situations that are important in terms of safety.

  • Immobilizer Interface

    The Immobilizer Interface is an accessory which is used for the cases when the car is stolen or when it is necessary to stop the car for safety purposes. If the vehicle is started when the vehicle’s engine is closed, the vehicle does not operate and there will be no impact while the vehicle is operating however, the vehicle will not restart after it has been stopped.

  • Audio Alarm Unit

    When the values of Over Speed Limit defined in the unit is exceeded, it is used to give an audio alarm in the vehicle at the beginning of idle running. It can also be activated/deactivated using the web page when desired.

  • Manhole Cover / Dumper Sensor

    The Manhole Cover Sensor is a metal accessory which is manufactured to resist the external factors. It can be used to follow the open/closed states of manhole covers of vehicles such as fuel tank etc. or the dumpers.

  • Special Use Control Button / Switch

    In order to prevent the vehicle from being monitored in private uses, the driver may prevent the generation of address information by activating this switch. Information such as the distance covered and the violation of the Over Speed Limit will continue to be generated.

  • CANBus Interface

    It is the interface with CANBus technology that obtains critical information such as vehicle fuel consumption, tank fuel level, engine speed (up to 50 sensors can be reached) from the on-board computer and puts them into the service of user. Data can be obtained from approximately 600 different brands/models of passenger cars or heavy vehicles without depending on FMS standard. Check the brand model information via Mobiliz for the compatibility of the vehicle (s) in which you consider using CANBus Interface.

  • Temperature Sensor

    The Temperature Sensor is an accessory ensuring that the temperature information of the ambient, in which the product carried during the transportation of cold chain products, is monitored in an integrated manner with the vehicle tracking system and that a warning is sent to the relevant persons via SMS and e-mail, in case temperature limits pre-registered in the sytem are exceeded. Temperature data can be obtained from 2 different points of vehicles with large trailer parts. Measurement of 0.5° sensitivity between -50 ° C and + 85 ° C can be made via digital sensor.

  • Driver ID Set

    The Driver ID Set is an accessory which can be used to determine the driver using the vehicle on the basis of date and time and to ensure that detailed driver-based reports on vehicle usage can be received. It is useful in companies where it is possible for the same driver to drive more than one vehicle. This product can be used in ways of different applications, depending on demand: 1- "Buzzer" Application: If the driver ID unit is not read after the vehicle is started, this gives high volume audio alarm upon request. "Audio Alarm Unit" is used as an addition for this application. 2- Application Where the Vehicle is not Started: With this application, the vehicle cannot be started without the driver ID unit is read. "Immobilizer Interface" is used as an addition for this application.

  • RFID Card Reader

    With the RFID Card Reader you can use the existing personnel cards of your company as driver ID. You can track when your vehicles are used and by which drivers. This product can be used in ways of different applications, depending on demand: 1- "Buzzer" Application: If the driver ID unit is not read after the vehicle is started, this gives high volume audio alarm upon request. "Audio Alarm Unit" is used as an addition for this application. 2- Application Where the Vehicle is not Started: With this application, the vehicle cannot be started without the driver ID unit is read. "Immobilizer Interface" is used as an addition for this application. Properties of the Cards: All cards operating at the 125 kHz radio communication frequency and compatible with this frequency can be read with the Proximity Card Reader. It can read the cards at ISO15693 Standard. All cards operating at the 13.56 MHz radio communication frequency and compatible with this frequency can be read with the Mifare Card Reader. It can read ISO14443, Mifare Classic 1K, 4K and Ultralight cards.

  • Fuel Sensor

    The fuel tank float can be used in vehicles supplying analogue voltage. The fuel level can be tracked as a percentage.

WHICH PRODUCT I SHOULD BUY?
ECONOMIC
STANDARD
ADVANCED
  • Web Based System Features
    Easy to use
    Quick access to summary information based on organization, fleet and group
    Ability to monitor the vehicles on the map by filtering according to 6 different options
    Vehicle-based adhoc query
    Periodical monitoring according to time
    Ability to get the density map of the vehicle or vehicles selected on the map at specific time intervals
    Tracking by entered and exited zones
    Tracking by control points
    Tracking by violation values
    Tracking feature on a map by vehicle, group, fleet and organization
    Daily vehicle-based briefing
    Daily vehicle-based detail information screens and animation feature
    Ability to query vehicles passing through a certain point
    Zoom-in, zoom-out features on the map, shifting of the map, focusing by the car
    Address, speed, total daily route, message warning and violation warning and number of vehicles on the same screen
    Easy user interface management
    Ability to authorize the user for monitoring by user types
    Driver identification and easy vehicle identification for drivers
    Ability to receive reports about vehicle, driver, violation, overtime, area-route sensor, trailer, voyage, user and road computer (Note1)
    Ability to receive automatic mailing by scheduling reports for the desired time
    Ability to receive the reports in pdf, excel and CSV formats
    Ability to receive the reports in 9 different languages
    Ability to see detailed notifications based on violation schedules defined for vehicles
    Access to educational videos of Expressive Web, Android and IOS applications
    Note1: Ability to report according to connected sensors
  • Programming Features (Tool and group basis)
    Determination of time frequency
    Determination of distance frequency
    Determination of turning angle
    Determination of violation parameters
     Time to commence work
    Time to quit work
    Speed ​​limit
    Instant idle time
    Instant stopped time
    Daily stopped time
    Daily movement time
    Limiting the number of drives if drive id units are used
     Sudden take-off/stop or accident reporting
    No GSM connection alert
    Motion alert when the ignition is off
    Sudden fuel low alert
    Motion without driver alert, if drive ID units are used
    Ability to receive all violations via mail
    GPS Antenna Breaking/Connection Status Information
    Ability to program modular sensors (temperature, fuel level, humidity level) in vehicles
    Ability to define periodical transactions (tax, maintenance, inspection ... etc.) of the vehicles and ability to receive alerts
  • Determination of Area Violation Parameters
    Entered zone alert
    Exited zone alert
    Enter/exit alerts in control points
  • Quick reporting opportunities
    Vehicle-based reports
    Violation Based Reports
    Driver Based reports
    Shift Reports
    Area / route reports
    Sensor reports
    Trailer based reports
    User reports
  • Input / Output
    Ignition switch input
    Emergency button
    Door / cover / damper / mixer sensor
    Fuel tank cover sensor
    Temperature sensor
    Driver ID set
    Card reader
    CANBus Accessory
    Canbus and Card Reader accessory together
    Immobilizer engine block
    In-car audio alarm
    Analogue fuel connection
    Opportunity to Use Built-in Battery
    Special case extra key
    Tachograph data download
  • Additional Software Applications
    Targetmatic
    My child is safe solution
    My Passenger is Safe Camera Monitoring System Compatibility
    Smart Bus Stop Tracking Software
    Compatibility with Excavation Software
    IPHONE / IPAD (iOS) Vehicle Tracking Application
    ANDROID Vehicle Tracking Application
    OGS / HGS pass feature
    Tachograph integration
- Includes
- Unavailable
- Optional Feature
