OBDII - Easy Package DT450NC

OBDII-Easy Package including vehicle tracking unit with OBDII Connector is easily installed into vehicle OBD (on Board diagnostic) connector and only used for monitoring the position, speed and total mileage. Through direct installation of vehicles into the OBD (on Board diagnostic) connector, it is a basic and economic package that is easy to install without cables. Through internal battery, it sends an alarm when it is removed from its place. It is ideal for applications which require frequent vehicle changes and do not require high security.

  • USAGE AREAS

    The connector vehicle tracking unit offered within the scope of OBDII-Simple Package is easily installed on the vehicle's OBD (on Board diagnostic) connector and is only used to track position, speed and total mileage. Thanks to the direct installation of vehicles on OBD (on Board diagnostic) connector, it is a basic and economic package that is easy to install without cables. Thanks to its built-in battery, it sends an alarm when it is removed from its place. It is ideal for applications that require frequent vehicle changes and do not require high security.

  • SPECIFICATIONS
    Network Specifications
    GSM/SMS/GPRS
    ✅
    GSM 900/1800/1900 MHz
    900/1800/1900 MHz
    Detection of the Roaming Operator
    -
    Physical Dimensions
    Dimensions
    48 * 25 * 48 mm
    Weight
    48 gr
    Connector
    OBDII
    Storage Temperature/Operating Temperature
    -40°C;+85°C / -30°C;+80°C (bataryasız)
    Power
    Input Voltage
    8-32 VDC
    Power Saving Mode (Hybernation)
    Var
    Antenna
    GPS
    Dahili
    GSM
    Dahili
    Hardware
    Telemetry
    OBDII
    Serial Port
    -
    Internal Battery
    Li-Polimer 130mAh
    Light Indicator
    Var
    Remote Firmware Upgrade
    ✅
    Message Memory (unit)
    10000 (arttırabilir)
    Telemetry Specifications
    Digital Outputs
    -
    Digital Inputs
    -
    Analogue Inputs
    -
    1-Wire
    -
    OBDII Port
    -
    GPS Receiver Specifications
    Technology
    u-blox All-in-One GPS Receiver
    Receiver Sensibility
    -162 dBm
    Cold Startup Time
    27 sn
    Hot Startup Time
    1 sn
    Warm Startup Time
    27 sn
    Antenna
    Dahili
    GPS Channel Number
    GPS+GLONASS 56 Kanal
    Protocol
    UDP Support
    ✅
    TCP/IP Support
    ✅
    SMS PDU
    ✅
    Dinamic IP Destek
    ✅
    Certificates
    CE
    ✅
    E-mark
    ✅
OBDII - Easy Package DT450NC ACCESSORIES
WHICH PRODUCT I SHOULD BUY?
OBDII - Easy Package
OBDII - Advanced Package
  • Web Based System Features
    Easy to use
    Quick access to summary information based on organization, fleet and group
    Ability to monitor the vehicles on the map by filtering according to 6 different options
    Vehicle-based adhoc query
    Periodical monitoring according to time
    Ability to get the density map of the vehicle or vehicles selected on the map at specific time intervals
    Tracking by entered and exited zones
    Tracking by control points
    Tracking by violation values
    Tracking feature on a map by vehicle, group, fleet and organization
    Daily vehicle-based briefing
    Daily vehicle-based detail information screens and animation feature
    Ability to query vehicles passing through a certain point
    Zoom-in, zoom-out features on the map, shifting of the map, focusing by the car
    Address, speed, total daily route, message warning and violation warning and number of vehicles on the same screen
    Easy user interface management
    Ability to authorize the user for monitoring by user types
    Driver identification and easy vehicle identification for drivers
    Ability to receive reports about vehicle, driver, violation, overtime, area-route sensor, trailer, voyage, user and road computer (Note1)
    Ability to receive automatic mailing by scheduling reports for the desired time
    Ability to receive the reports in pdf, excel and CSV formats
    Ability to receive the reports in 9 different languages
    Ability to see detailed notifications based on violation schedules defined for vehicles
    Access to educational videos of Expressive Web, Android and IOS applications
    Note1: Ability to report according to connected sensors
  • Programming Features (Tool and group basis)
    Determination of time frequency
    Determination of distance frequency
    Determination of turning angle
    Determination of violation parameters
     Time to commence work
    Time to quit work
    Speed ​​limit
    Instant idle time
    Instant stopped time
    Daily stopped time
    Daily movement time
    Limiting the number of drives if drive id units are used
     Sudden take-off/stop or accident reporting
    No GSM connection alert
    Motion alert when the ignition is off
    Sudden fuel low alert
    Motion without driver alert, if drive ID units are used
    Ability to receive all violations via mail
    GPS Antenna Breaking/Connection Status Information
    Ability to program modular sensors (temperature, fuel level, humidity level) in vehicles
    Ability to define periodical transactions (tax, maintenance, inspection ... etc.) of the vehicles and ability to receive alerts
  • Determination of Area Violation Parameters
    Entered zone alert
    Exited zone alert
    Enter/exit alerts in control points
  • Quick reporting opportunities
    Vehicle-based reports
    Violation Based Reports
    Driver Based reports
    Shift Reports
    Area / route reports
    Sensor reports
    Trailer based reports
    User reports
  • Input / Output
    Ignition switch input
    Emergency button
    Door / cover / damper / mixer sensor
    Fuel tank cover sensor
    Temperature sensor
    Driver ID set
    Card reader
    CANBus Accessory
    Canbus and Card Reader accessory together
    Immobilizer engine block
    In-car audio alarm
    Analogue fuel connection
    Opportunity to Use Built-in Battery
    Special case extra key
    Tachograph data download
  • Additional Software Applications
    Targetmatic
    My child is safe solution
    My Passenger is Safe Camera Monitoring System Compatibility
    Smart Bus Stop Tracking Software
    Compatibility with Excavation Software
    IPHONE / IPAD (iOS) Vehicle Tracking Application
    ANDROID Vehicle Tracking Application
    OGS / HGS pass feature
    Tachograph integration
- Includes
- Unavailable
- Optional Feature
