It
is a package that allows a great number of sensors and external unit
connections in addition to the Battery Standard Package.
-
USAGE AREAS
It is the package suggested for the situations requiring a large number of different sensor connections other than the basic tracking features in terms of application.
-
SPECIFICATIONSNetwork SpecificationsGSM/SMS/GPRS✅GSM 900/1800/1900 MHz900/1800/1900 MHzDetection of the Roaming Operator✅Physical DimensionsDimensions80* 49 * 26 mmWeight71 grConnector16 pin Molex, otomotiv uygunStorage Temperature/Operating Temperature-40°C;+80° / -30°C; +80°CPowerInput Voltage8-32 VDCPower Saving Mode (Hybernation)VarAntennaGPSDahili (harici anten ops.)GSMDahiliHardwareTelemetry4 Dijital + 1 Analog Giriş, 3 Dijital ÇıkışSerial PortVarInternal BatteryLi-Polimer 250mAhLight IndicatorVarRemote Firmware Upgrade✅Message Memory (unit)10000 (arttırabilir)Telemetry SpecificationsDigital Outputs3Digital Inputs4 (1 kontakt)Analogue InputsYapılandırılabilir 2 adet1-Wire-OBDII PortGPS Receiver SpecificationsTechnologyu-blox All-in-One GPS ReceiverReceiver Sensibility-162 dBmCold Startup Time27 snHot Startup Time1.2 snWarm Startup Time27 snAntennaDahili (harici anten ops.)GPS Channel NumberGPS+GLONASS 56 KanalProtocolUDP Support✅TCP/IP Support✅SMS PDU✅Dinamic IP Destek✅CertificatesCE✅E-mark✅
-
Emergency Call Button
The Emergency Call Button can be used for sending an emergency call message to the centre, in cases of a malfunction, an accident or cases where it is necessary to take security precautions in the vehicle. The vehicle is taken under monitor by the centre. In Economics Package, the Emergency Call Button can not be used with Tank, Door Cover, Manhole Cover and Damper Sensors at the same time.
-
Tank / Door Cover Sensor
The Door Sensor is an accessory that provides information regarding whether the vehicle’s door or the covers of the fuel tank etc. are open or closed. It can be used in cases of uncontrolled fuel supply, fuel stealing risk and situations that are important in terms of safety.
-
Immobilizer Interface
The Immobilizer Interface is an accessory which is used for the cases when the car is stolen or when it is necessary to stop the car for safety purposes. If the vehicle is started when the vehicle’s engine is closed, the vehicle does not operate and there will be no impact while the vehicle is operating however, the vehicle will not restart after it has been stopped.
-
Audio Alarm Unit
When the values of Over Speed Limit defined in the unit is exceeded, it is used to give an audio alarm in the vehicle at the beginning of idle running. It can also be activated/deactivated using the web page when desired.
-
Manhole Cover / Dumper Sensor
The Manhole Cover Sensor is a metal accessory which is manufactured to resist the external factors. It can be used to follow the open/closed states of manhole covers of vehicles such as fuel tank etc. or the dumpers.
-
Special Use Control Button / Switch
In order to prevent the vehicle from being monitored in private uses, the driver may prevent the generation of address information by activating this switch. Information such as the distance covered and the violation of the Over Speed Limit will continue to be generated.
-
CANBus Interface
It is the interface with CANBus technology that obtains critical information such as vehicle fuel consumption, tank fuel level, engine speed (up to 50 sensors can be reached) from the on-board computer and puts them into the service of user. Data can be obtained from approximately 600 different brands/models of passenger cars or heavy vehicles without depending on FMS standard. Check the brand model information via Mobiliz for the compatibility of the vehicle (s) in which you consider using CANBus Interface.
-
Temperature Sensor
The Temperature Sensor is an accessory ensuring that the temperature information of the ambient, in which the product carried during the transportation of cold chain products, is monitored in an integrated manner with the vehicle tracking system and that a warning is sent to the relevant persons via SMS and e-mail, in case temperature limits pre-registered in the sytem are exceeded. Temperature data can be obtained from 2 different points of vehicles with large trailer parts. Measurement of 0.5° sensitivity between -50 ° C and + 85 ° C can be made via digital sensor.
-
Driver ID Set
The Driver ID Set is an accessory which can be used to determine the driver using the vehicle on the basis of date and time and to ensure that detailed driver-based reports on vehicle usage can be received. It is useful in companies where it is possible for the same driver to drive more than one vehicle. This product can be used in ways of different applications, depending on demand: 1- "Buzzer" Application: If the driver ID unit is not read after the vehicle is started, this gives high volume audio alarm upon request. "Audio Alarm Unit" is used as an addition for this application. 2- Application Where the Vehicle is not Started: With this application, the vehicle cannot be started without the driver ID unit is read. "Immobilizer Interface" is used as an addition for this application.
-
RFID Card Reader
With the RFID Card Reader you can use the existing personnel cards of your company as driver ID. You can track when your vehicles are used and by which drivers. This product can be used in ways of different applications, depending on demand: 1- "Buzzer" Application: If the driver ID unit is not read after the vehicle is started, this gives high volume audio alarm upon request. "Audio Alarm Unit" is used as an addition for this application. 2- Application Where the Vehicle is not Started: With this application, the vehicle cannot be started without the driver ID unit is read. "Immobilizer Interface" is used as an addition for this application. Properties of the Cards: All cards operating at the 125 kHz radio communication frequency and compatible with this frequency can be read with the Proximity Card Reader. It can read the cards at ISO15693 Standard. All cards operating at the 13.56 MHz radio communication frequency and compatible with this frequency can be read with the Mifare Card Reader. It can read ISO14443, Mifare Classic 1K, 4K and Ultralight cards.
-
Fuel Sensor
The fuel tank float can be used in vehicles supplying analogue voltage. The fuel level can be tracked as a percentage.
-
Hands-Free Audio Kit
The Hands-Free Audio Kit is an accessory that enables to make voice calls between the driver and the centre and to listen to the vehicle remotely when desired. In addition, in cases of emergency, it can be ensured that the vehicle to call the centre quietly and inside the vehicle can be listened.
-
Web Based System FeaturesEasy to useQuick access to summary information based on organization, fleet and groupAbility to monitor the vehicles on the map by filtering according to 6 different optionsVehicle-based adhoc queryPeriodical monitoring according to timeAbility to get the density map of the vehicle or vehicles selected on the map at specific time intervalsTracking by entered and exited zonesTracking by control pointsTracking by violation valuesTracking feature on a map by vehicle, group, fleet and organizationDaily vehicle-based briefingDaily vehicle-based detail information screens and animation featureAbility to query vehicles passing through a certain pointZoom-in, zoom-out features on the map, shifting of the map, focusing by the carAddress, speed, total daily route, message warning and violation warning and number of vehicles on the same screenEasy user interface managementAbility to authorize the user for monitoring by user typesDriver identification and easy vehicle identification for driversAbility to receive reports about vehicle, driver, violation, overtime, area-route sensor, trailer, voyage, user and road computer (Note1)Ability to receive automatic mailing by scheduling reports for the desired timeAbility to receive the reports in pdf, excel and CSV formatsAbility to receive the reports in 9 different languagesAbility to see detailed notifications based on violation schedules defined for vehiclesAccess to educational videos of Expressive Web, Android and IOS applicationsNote1: Ability to report according to connected sensors
-
Programming Features (Tool and group basis)Determination of time frequencyDetermination of distance frequencyDetermination of turning angleDetermination of violation parametersTime to commence workTime to quit workSpeed limitInstant idle timeInstant stopped timeDaily stopped timeDaily movement timeLimiting the number of drives if drive id units are usedSudden take-off/stop or accident reportingNo GSM connection alertMotion alert when the ignition is offSudden fuel low alertMotion without driver alert, if drive ID units are usedAbility to receive all violations via mailGPS Antenna Breaking/Connection Status InformationAbility to program modular sensors (temperature, fuel level, humidity level) in vehiclesAbility to define periodical transactions (tax, maintenance, inspection ... etc.) of the vehicles and ability to receive alerts
-
Determination of Area Violation ParametersEntered zone alertExited zone alertEnter/exit alerts in control points
-
Quick reporting opportunitiesVehicle-based reportsViolation Based ReportsDriver Based reportsShift ReportsArea / route reportsSensor reportsTrailer based reportsUser reports
-
Input / OutputIgnition switch inputEmergency buttonDoor / cover / damper / mixer sensorFuel tank cover sensorTemperature sensorDriver ID setCard readerCANBus AccessoryCanbus and Card Reader accessory togetherImmobilizer engine blockIn-car audio alarmAnalogue fuel connectionOpportunity to Use Built-in BatterySpecial case extra keyTachograph data download
-
Additional Software ApplicationsTargetmaticMy child is safe solutionMy Passenger is Safe Camera Monitoring System CompatibilitySmart Bus Stop Tracking SoftwareCompatibility with Excavation SoftwareIPHONE / IPAD (iOS) Vehicle Tracking ApplicationANDROID Vehicle Tracking ApplicationOGS / HGS pass featureTachograph integration
